Betta SE Plus Smart Pool Skimmer

Betta is a smart pool skimmer that mostly runs by itself. It works as a pool surface cleaner/skimmer and is powered completely by the solar panel that charges the built-in battery. Betta is fully self-driving unless controlled by the optional remote included. It has a control system with various sensors including a Gyroscope to guide itself while maneuvering on the pool surface. The unit picks up floating debris in its path and collects it into the removable collection basket inside. Betta runs 100% on solar energy and does NOT have any AC/DC/USB charging ports. The unit has a high-capacity top solar panel that charges the battery when there is sunlight and manages the operation automatically based on the battery charge.

Important Safety Instructions

DO NOT SWIM while Betta is working in the pool. Take it out of the pool and keep it at a cool place under the shade when the pool is in use.

Betta Smart Pool Skimmer is NOT a toy. Keep it away from children.

Be sure to watch your steps and maintain your balance when working by the poolside.

Do not use it while other pool cleaning devices are in the pool.

During swimming season, keep Betta in the pool all the time unless the pool is in use or the unit needs cleaning or service.

Do NOT leave Betta in a hot and dry spot out of the pool unattended to avoid severe damage to the unit.

Do NOT wash Betta using a pressure washer as it would cause damage to the unit.

Components

Using Betta

Note: Betta ONLY takes solar charge when power switch is ON

Be sure to watch your steps and maintain your balance when working by the pool side.
Step 1. Slide the power switch to the position that you can see “ON” mark to turn on the unit. LED status indicators at front will flash and then the propellers and impeller will start running.
Step 2. Place Betta into your pool and it will start moving and cleaning the pool’s surface.

Betta runs in either Auto Mode or Remote Control Mode during operation.
Auto Mode
Betta is designed and programmed to be fully self-driving. It maneuvers and guides itself by reading the sensors and managing operations and charging smartly on its own. By default, the unit will be working in Auto Mode unless it’s operated by the remote control.
Remote Control Mode
You can manually control Betta’s movement and travel path in the pool using included remote control when needed. For example, if you want Betta to go left, just press and hold the left button on the remote. Remote Mode gives you fast control to move Betta wherever you want.

Pairing Betta with a New Remote
The remote control packed with Betta has been paired in the factory.
You only need to do this step if it doesn’t work, or you replaced it with a new one.
First, slide the power to “OFF” position to turn off the unit. Second, slide the switch to “ON” to turn it on. Press any button once on the remote control within 5 seconds after you turn on the unit. Test the buttons on the remote after the 5 seconds and see if the unit is moving accordingly. If yes, the paring completes. If not, repeat this process from the beginning. If no success on paring, please contact Betta customer service.

Using Remote Control
You should be able to use the remote control out of the box since it’s paired with your Betta in the factory. You only need to pair it if it doesn’t work, or you replaced either the Betta unit or the remote control.
Press any button on the remote control. Betta will instantly enter Remote Control Mode. Press and hold the left button to move Betta left, press and hold the right button to move Betta right, so on and so forth.
To go back to Auto Mode, press the middle button down for 2 seconds, and Betta will go back to Auto. Also, if you do not operate Betta with the remote control for 2 minutes, it will go back to Auto Mode by itself.
LED light status indicators (one on each side at front) will show the operation status information of working conditions of the unit.
Standard Mode: lights flash in Green.
Status: there is enough power, the unit will keep running.
Intermittent Mode: lights flash in Red.
Status: the battery is low; the unit is running at irregular intervals in attempts to locate sunlight where it can be recharged.
Sleep Mode: all indicator lights are off.
Status: the battery is very low, or battery becomes completely discharged.
Remote Mode: lights are in steady Green.
Status: the unit is controlled manually via a remote control.
Strand Mode: lights flash in combination of Red and Green.
Status: the unit's propellers or impeller is not working properly, most likely it has been stuck by obstacles or cannot run freely. In this case it will stop running automatically. The unit will try to restart every 20 minutes when it is in Strand Mode.
When to use:
If there are shallow stairs or other structures in your pool, Betta may be stuck on it. You can adjust the built-in anti-stranding bars to solve this problem.
How to use:
Press the upper button on the bar housing and pull down the bars. Each bar can be set in two positions in height. Adjust them in pairs – both front and/or both rear to keep it balanced.

Retrieving the anti-stranding bars: Press the lower button on the bar housing and push the bar up until it’s fully in position.


During winter months, the battery may not get a full charge because the sunlight is not as strong as during summer. Therefore, you should expect Betta to have a shorter run time than in the summer. Even in a sunny winter climate like CA, FL, and AZ, you will not get as fast charge as in the summer, and a full charge will need a longer period.

Troubleshoot

Possible reason What to Do

The unit is in Sleep Mode. The status lights are off, indicating the battery level is very low or completely discharged.

Leave the unit in the pool. After sunrise the next day, the unit will start running in intervals in attempts to locate spots with good sunlight where it can be recharged. You may manually place it in the direct sunlight to charge it faster.

Possible reason What to Do

Scenario 1: The unit is in Intermittent Mode – the status lights are flashing in Red, indicating the batter is low.

You may leave it as is in the pool, the unit will run in intervals in attempts to locate sunlight where it can be recharged.

Scenario 2: The unit is in Sleep Mode. The status lights are off, indicating the battery level is very low or completely discharged.

Try to place it in the spot that has direct sunlight in the pool and wait until it gets some charge.

Scenario 3: The unit is in Strand Mode. Status lights are flashing in Red and Green indicating Betta is stuck at some structures, such as stairs, stools, or propeller/impeller is strapped by something.

  • Be patient and wait for a few minutes. The unit will try restarting every 20 minutes when it is in Strand Mode.
  • Ensure that the basket is in place, and the Cover Lock is properly secured.
  • Check propellers and Impeller for dirt, string, or hair.
Possible reason What to Do
  1. The solar panel has residues.
  2. Propeller or Impeller is strapped.
  • Clean the solar panels.
  • Ensure propellers and Impeller are turning freely.
Possible reason What to Do

One or both propellers are trapped which makes the unit running unbalanced.

Check propellers and Impeller for dirt, string, and hair.

Possible reason What to Do
  1. The solar panel has residues.
  2. Propeller or Impeller is strapped.
  • Clean the solar panels.
  • Ensure propellers and Impeller are turning freely.

Warranty Information

Betta is designed to work in fresh water or salty water up to 5000 P.P.M. The unit comes with 1-Year Manufacturer’s Warranty from the date of purchase. Using the unit in sea water pools will void the warranty. If you have any issues or concerns, please contact us directly. Betta honors extended warranty ONLY through Betta Care. Any other offers from third-party retailers will not be serviced by Betta directly. If you have any questions about Betta warranty, please contact us at info@BettaBot.com or 888-692-3882.

Warranty Registration: www.bettabot.com/pages/warranty-registration

Extended Warranty (Betta Care): www.bettabot.com/pages/warranty
